AXIOM 7 Touch with integrated 600 W Sonar and DownVision

E70364-00
896.45

AXIOM 7 DV navigation display with built-in 600W sonar and DownVision under-boat scanning technology offers a variety of functions including bottom contouring and fish hunting. Chirp technology provides high detalization. Buy a Raymarine Marine Display AXIOM 7 DV 600 W and manage several processes on the ship at once: geolocation, underwater exploration, cartography and fish finding.

Taxes
Delivery
topRik
Nautical marketplace, yacht charter agency, equipment supplier, new yachts sales, brok...
+38269541228
Ask a question
BrandRaymarine Shipping fromFrance Model numberE70364-00

Raymarine AXIOM 7 DV with powerful 600 W sonar and DownVision sonar for underwater exploration is not a simple chartplotter, but a full-fledged marine display that successfully performs the following tasks:

  • calculates and lays a route on the map indicating waypoints, ports, tides and currents with related information;
  • quickly determines the location of the vessel in real time to monitor compliance with the route;
  • promptly displays seamless maps with the required information;
  • records in real time the path of the vessel;
  • explores and displays a bottom topography map with parameters;
  • explores and shows the underwater space with high detail;
  • detects the accumulation of fish or individual individuals.

Only the features provided by the built-in sonars are listed. Basic characteristics and capabilities are preserved. This is a powerful quad-core processor that allows you to quickly issue commands and receive feedback through anti-glare multi-touch.

LightHouse 3 operating system is rich with features and supports the best C-MAP and Navionics cartography in addition to its own maps.

It remains possible to control the display remotely via a smartphone using the appropriate applications.

You can buy the AXIOM 7 DV marine display and expand its capabilities over time, thanks to its open platform. All Raymarine navigation instruments and equipment are compatible with it.

Features of AXIOM 7 Touch with integrated 600 W Sonar and DownVision

    Brand
    Raymarine
    Voltage, V DC
    12 (8 to 16)
    Weight, kg
    1.52
    EAN
    00723193823231
    Operating temperature
    -25 to +55 °C
    Main features
    Model number
    E70364-00
    Display size, inch
    7
    With transducer
    No
    NMEA0183
    No
    Bluetooth
    Yes
    Sonar module
    Yes
    Installation height, mm
    120
    Installation width, mm
    188
    Sea Charts
    C-MAP 4D, Navionics+, Navionics Platinum+, LightHouse Charts
    Radar capable
    Yes
    Operating mode
    Touch screen
    NMEA2000
    Yes
    WiFi
    Yes
    Ethernet / Network
    Yes
    Nautical chart support
    Yes
    Tablet control
    Yes
    Technical data
    Video/camera
    Up to 10 IP cameras
    Resolution, mm
    800 x 480 WVGA
    Brightness, nits
    1200
    Viewing angle, °
    60 / 70 / 70 / 70 (Top / Bottom / Left / Right)
    Power consumption, W
    10.02
    Ethernet, ports
    Yes, 1x port (RayNet)
    NMEA2000, ports
    Yes, 1x port (Micro C)
    NMEA0183
    No
    SeaTalkNG
    Adapter cable necessary
    USB
    1x USB mircoAB
    GPS
    Integrated (10 Hz, 28 channel) GPS/GLONASS/Galileo/Beidou
    Sonar
    Integrated
    Radar
    Compatible with Quantum, Digital, HD Color/Super HD Colour and Magnum radar antennas
    AIS
    Yes, via NMEA2000
    Card slot
    1x
    Autopilot operation
    Evolution autopilot
    Storage temperature
    -30 to +70 °C
    Thermal image
    FLIR AX8, M232, M300 series, M400, M500
    Waterproof
    IPX6 / IPX7
    Dimensions, mm
    250.4 x 133 x 76.4
