AXIOM+ 12 Touch

26180
2,454.08
In stock

Multifunctional multi touch chartplotter Raymarine Axiom+ 12 with a wide viewing angle (88° on all 4 sides) is equipped with an intuitive LightHouse 3 operating system to master. OS configuration is easily customized to individual requirements with a choice of map modes: standard, detailed, fishing. Buying an AXIOM+ 12 display is a guarantee of safe sailing, successful fishing, as well as a pleasant stay with a view of the underwater world.

BrandRaymarine Shipping fromCroatia Model numberE70638 Display size, inch12
topRik
Nautical marketplace, yacht charter agency, equipment supplier, new yachts sales, brok...
+37253060890
Ask a question
Contact

English / Hrvatski / Русский

Messengers: All languages

Taxes

The price provided is NET-price, meaning shipment and VAT are not included. Additional duties and tax payments might be required. Taxes and delivery costs are calculated after ordering the goods and depend on the type of client and delivery address.

Delivery
Returns
Brand
Raymarine
Voltage, V DC
12 (8 to 16)
Weight, kg
2.72
EAN
00723193836958
Operating temperature
-25 to +55 °C
Main features
Model number
E70638
Display size, inch
12
With transducer
No
NMEA0183
No
Bluetooth
Yes
Sonar module
Optional
Installation height, mm
205
Installation width, mm
302
Sea Charts
C-MAP 4D, Navionics+, Navionics Platinum+, LightHouse Charts
Radar capable
Yes
Operating mode
Touch screen
NMEA2000
Yes
WiFi
Yes
Ethernet / Network
Yes
Nautical chart support
Yes
Tablet control
Yes
Technical data
Video/camera
Compatible with CAM210IP and CAM220IP (max. 10 cameras)
Resolution, mm
1280 x 800
Brightness, nits
1800
Viewing angle, °
88° top, bottom, left, right
Power consumption, W
15.48
Ethernet, ports
Yes, 1x port (RayNet)
NMEA2000, ports
Yes, 1x port (Micro C)
NMEA0183, ports
No
SeaTalkNG
Adapter cable necessary
USB
1x USB mircoAB
GPS
Integrated (10 Hz, 28 channel) GPS/GLONASS/Galileo/Beidou
Sonar
Integrated
Radar
Compatible with Quantum, Digital, HD Color/Super HD Colour and Magnum radar antennas
AIS
Yes, via NMEA2000
Card slot
1x
Autopilot operation
Evolution autopilot
Storage temperature
30 to +70 °C
Thermal image
FLIR AX8, M232, M300 series, M400, M500
Waterproof
IPX6 / IPX7
Dimensions, mm
314 x 217 x 77
Find similar

Reliability, ease of use and quality of the end result - these are the constant properties of the navigation equipment of the Raymarine line and the multifunctional display AXIOM+ 12 with a diagonal of 12.1"

  1. The use of CHIRP technology provides accurate tracking and detailing of the bottom relief at significant depths at high speed, determines the distance between objects as accurately as possible, provides a realistic image of the underwater space and its inhabitants.
  2. The shock-resistant multi-touch screen is protected by HydroTough coating, which repels moisture and dirt without compromising the quality and speed of touch control of the fish finder.
  3. 4-core processor provides high performance and instant responsiveness to commands, provides fast display from radar, smoothly and quickly generates maps in high quality.
  4. Some of the best Navionics and C-MAP electronic navigation charts are supported, as well as Lighthouse operating system charts.
  5. The position of the vessel is determined by a highly sensitive receiver with 72 GPS/GNSS channels.
  6. The operating program with built-in day/night mode allows you to adjust the image under different lighting conditions.
  7. You can control your fishfinder remotely using a Wi-Fi or Bluetooth connection.

The chartplotter comes with two mounting options - flush on a panel or on a bracket.

It is possible to buy an Axiom+ 12 display with additional peripherals as the fish finder is compatible with all Raymarine navigation instruments.
