Phoenix MultiPlus-II 24/5000/120-50 Inverter/Charger

PMP242505010
1,636.00
In stock
Uflex s.r.l.
topRik
Nautical marketplace, yacht charter agency, equipment supplier, new yachts sales, brok...
+37253060890
Ask a question
Contact

English / Hrvatski / Русский

Messengers: All languages

Taxes

The price provided is NET-price, meaning shipment and VAT are not included. Additional duties and tax payments might be required. Taxes and delivery costs are calculated after ordering the goods and depend on the type of client and delivery address.

Delivery
Returns
BrandVictron Energy Shipping fromCroatia
AC-connection
Screw terminals 13 mm² (6 AWG)
Battery-connection
M8 bolts
Charge voltage ‘absorption’,V (DC)
28,8
Charge voltage ‘float’,V (DC)
27,6
Depth, mm
149
Device type
Charger + Inverter
Frequency, Hz
50
Humidity (non condensing)
max 95%
Input voltage, V (AC)
187 - 265
Input voltage, V (DC)
19–33
Protection
a-g
Protection category, IP
IP22
Temperature sensor
Yes
Width, mm
330
Brand
Victron Energy
Operating temperature
-40 to +65ºC
Dimensions in packaging
Weight, kg
30
Main characteristics
Height, mm
607
Additional Information
MPN
PMP242505010
Find similar

The MultiPlus-II combines the functions of the MultiPlus and the MultiGrid.
It has all the features of the MultiPlus, plus an external current transformer option to implement PowerControl and PowerAssist and to optimize self-consumption with external current sensing (max. 32A).
It also has all the features of the MultiGrid with built-in anti-islanding and an increasingly long list of country approvals.

Note: for a short period of time this product was called MultiGrid-II.

Additional materials

Data Sheet (Datasheet-MultiPlus-II-inverter-charger-EN.pdf, 586 Kb) [Download]
