AC-connection
Screw-terminal 6 AWG (13mm²)
Battery-connection
M8 bolts
Charge voltage ‘absorption’,V (DC)
14,4
Charge voltage ‘float’,V (DC)
13,8
Charging Current, A
120
Depth, mm
218
Device type
Charger + Inverter
Frequency, Hz
60
Humidity (non condensing)
max 95%
Input voltage, V (AC)
95-140
Input voltage, V (DC)
9.5 - 17
Protection
a-g
Protection category, IP
IP 21
Width, mm
258
Brand
Victron Energy
MPN
PMP123021010
Weight, kg
19
EAN
8719076023951
Operating temperature
-40 to +65ºC
Main characteristics
Height, mm
362
The MultiPlus, as the name suggests, is a combined inverter and charger in one elegant package. Its many features include a true sine wave inverter, adaptive charging, hybrid PowerAssist technology, plus multiple system integration features.
