SinusMax: Engineered for professional-grade applications, this inverter range achieves optimal efficiency while maintaining superior performance. Its design centers on delivering a true sine wave inverter through hybrid HF technology, resulting in a compact, lightweight product capable of seamlessly powering diverse loads.
Noteworthy is the remarkable start-up power of SinusMax technology, surpassing conventional high-frequency options. This feature positions the inverters as ideal for challenging loads like refrigeration compressors and electric motors.
Versatility is a hallmark, allowing up to six units to operate in parallel, providing expanded power output, with three-phase configuration also feasible.
For load transfer to an alternate AC source, the integrated automatic transfer switch ensures uninterrupted power. Alternatively, the MultiPlus inverter/charger is recommended, boasting a swift switchover time.
Facilitating user customization, the larger inverter models incorporate a VE.Bus port for easy PC connection using the MK3-USB VE.Bus to USB interface. Free VictronConnect or VEConfigure software enables parameter adjustments, covering output voltage, frequency, over and under voltage settings, and relay programming. The relay serves various functions, from signaling alarms to initiating a generator. Connection to a GX device (e.g., Cerbo GX) allows for comprehensive monitoring and control.
For a deeper exploration of the potential applications of paralleled high-power inverters, consult the book 'Energy Unlimited,' offering insights, examples, and battery capacity calculations.
