Skylla-TG 24/50 3-phase (1+1)

STG024050300
1,066.00
In stock
Uflex s.r.l.
topRik
Nautical marketplace, yacht charter agency, equipment supplier, new yachts sales, brok...
+37253060890
Ask a question
Contact

English / Hrvatski / Русский

Messengers: All languages

Taxes

The price provided is NET-price, meaning shipment and VAT are not included. Additional duties and tax payments might be required. Taxes and delivery costs are calculated after ordering the goods and depend on the type of client and delivery address.

Delivery
Returns
Battery capacity, Ah250-500 BrandVictron Energy Shipping fromCroatia
AC-connection
screw-clamp 2,5 mm² (AWG 6)
Battery capacity, Ah
250-500
Battery-connection
M8 studs
Charge characteristic
IUoUo (three step)
Charge voltage ‘absorption’,V (DC)
28.5
Charge voltage ‘float’,V (DC)
26.5
Charging Current, A
50
Depth, mm
257
Device type
Charger
Frequency, Hz
45-65
Humidity (non condensing)
max 95%
Input voltage, V (AC)
320-450
Power factor
1
Protection
a,b,c,d
Protection category, IP
IP 21
Temperature sensor
Yes
Width, mm
250
Brand
Victron Energy
EAN
8719076026679
Operating temperature
-40 to +50°C
Dimensions in packaging
Weight, kg
13
Main characteristics
Height, mm
365
Additional Information
MPN
STG024050300
Find similar

One full rated output and one 4 Amp output. Charge voltage can be precisely adjusted to suit any battery system. The input for the charger is 230V at 50/60HZ. Charge voltage can be measured directly on the battery terminals in order to compensate for voltage loss due to cable resistance. An external sensor allows measuring battery temperature and compensating charge voltage accordingly.

Additional materials

Data Sheet (Datasheet-SkyllaTG-Charger-EN.pdf, 296 Kb) [Download]
