EasyCharge Charger - 12V/10A - 2 Outputs

3941013
132.93
List price: 147.70  -10%
In stock

Waterproof, durable chargers meeting IP68 standards for harsh environments

«Sense and Send» technology prioritizes charging for efficient energy distribution

Versatile compatibility with flooded, AGM, and Gel batteries, supporting global use

FNI
topRik
Nautical marketplace, yacht charter agency, equipment supplier, new yachts sales, brok...
+37253060890
Ask a question
Contact

English / Hrvatski / Русский

Messengers: All languages

Taxes

The price provided is NET-price, meaning shipment and VAT are not included. Additional duties and tax payments might be required. Taxes and delivery costs are calculated after ordering the goods and depend on the type of client and delivery address.

Delivery
Returns
Battery capacity, Ah20 - 120 Shipping fromItaly BrandMastervolt

Designed for durability and reliability, fixed-mount, waterproof battery charger is encased in an epoxy-filled, non-corrosive enclosure, meeting stringent IP68 waterproofing standards and complying with global regulations such as CE, CSA, CEC, and ABYC. The outputs are fully isolated, offering versatility in series or parallel configurations for increased voltage or current, supporting both 12V and 24V outputs.

Efficiency and Ease of Use

Highly efficient and user-friendly, these chargers are tailored for harsh environments, undergoing rigorous salt, shock, and vibration testing. Currently available in 6A single bank and 10A dual bank configurations, they are built to withstand demanding conditions.

Key Technological Advancements

A standout feature is the «Sense and Send» technology, enabling the chargers to identify batteries requiring priority charging, ensuring efficient energy distribution. Compatible with wet, AGM, and Gel batteries, these chargers feature a universal input (120-230V), providing worldwide compatibility and flexibility.

Features:

  • Entry-level model featuring Mastervolt's 3-step+ charge characteristic.
  • Compatible with Gel, AGM, and flooded batteries.
  • Full power operational up to 40°C.
  • Quick charging function enhances battery longevity.
  • Includes cable & Euro plug (UK plug option available).
  • Able to charge either one or two sets of batteries.
  • Sense-Send™ technology determines the prioritized battery for charging.
  • Supports series and parallel configuration.
  • Resistant to stains and waterproof for durability.
  • Internationally certified for quality assurance.
AC-connection
1.2 m (4 ft) cable + Euro plug
Battery capacity, Ah
20 - 120
Charge characteristic
IUoUo, automatic 3-step+ for Gel/AGM/flooded
Charge voltage ‘absorption’,V (DC)
14.3
Charge voltage ‘float’,V (DC)
13.3
Charging Current, A
10
Charging outputs
2
Device type
Charger
Dimensions, mm
127x178x51
Frequency, Hz
50 - 60Hz
Humidity (non condensing)
max 95 %
Input voltage, V (AC)
120 - 230
Integrated fan
No
Protection
Spark free, short circuit, reverse polarity, over voltage, current limited, over temperature
Protection category, IP
IP68
Width, mm
332.0
Operating temperature
-20 °C to +50 °C
Brand
Mastervolt
EAN
8168820204830
Dimensions in packaging
Weight, kg
8.1
Height, mm
157.0
Length, mm
500.0
Volume, cm3
26.06
Unit type
N
Additional Information
MPN
43321000
Additional materials

Datasheet (Datasheet_easycharge-10a.pdf, 661 Kb) [Download]

User Manual (Manual_EasyChargeOnboard_EN.pdf, 435 Kb) [Download]

No reviews found
