The SmartSolar MPPT RS solar charge controllers from Victron are ideal for large off-grid and grid-connected battery systems, featuring models with 5.76kW and 11.52kW capacities. With an operational solar voltage input range of 80-450 VDC, independent tracking inputs, active cooling, and fully programmable battery charging parameters, these controllers offer advanced functionality. The metal case design enhances safety, and covered electrical connections present a modern look. The controllers efficiently charge 48V battery banks with options for 100A or 200A.
Key Features:
Wide Voltage Input:
- Operates with a solar voltage input range of 80-450 VDC, suitable for large PV arrays.
Versatile Charging:
- Fully programmable charging parameters adaptable to various battery chemistries such as lead-acid and lithium.
Remote Monitoring:
- Allows Bluetooth connectivity for remote control and configuration via the VictronConnect App.
- VE.Can bus ports facilitate communication with additional SmartSolar RS & VE.Can MPPT units, enabling synchronization and monitoring via a GX device like the Cerbo GX.
Victron Remote Management:
- Enables remote monitoring through the Victron Remote Management Portal (VRM) when connected to the internet.
- VRM access provides real-time information and control over the SmartSolar RS charge controllers.
Display Panel:
- Equipped with a front-panel display showing battery volts, charge current, and voltages from individual arrays.
- Displays instantaneous and total figures, unit status, and error codes.
Additional Features:
- Programmable relay, options for remote temperature and voltage sensing, and compatibility with various BMS systems for charging control.
- The SmartSolar RS charge controller delivers advanced features, versatility, and remote management capabilities for efficient solar charging in large-scale applications.
