Charge Controller FOX-220
The price provided is NET-price, meaning shipment and VAT are not included. Additional duties and tax payments might be required. Taxes and delivery costs are calculated after ordering the goods and depend on the type of client and delivery address.
The FOX-320 / FOX-220 solar charge regulators are for charging currents up to 20 A, suitable for AGM, GEL and lead-acid batteries. With the FOX-320 two different battery systems can be charged. The optimized charging characteristic, in combination with the hardware PWM control, results in a considerably faster and more gentle charging of the battery. Hazardous gassing and/or overcharging are safely prevented.
The deep discharge protection is designed for consumers up to a maximum current consumption of 20A.
The FOX-MD1 is a remote display for the FOX-220 and FOX-320 and is simply connected with the prefabricated cable. The data measured by the FOX devices can be read comfortably in the 2-line display with large characters. In addition to pure text outputs, bar charts are also available for the charge status of the batteries.
Automatic 12V / 24V detection
The controller automatically detects the system voltage. The active back-current blocking device ensures reverse current protection and allows an extremely low voltage drop between the module and the battery. Der Regler erkennt die Systemspannung vollautomatisch.
Extensions
The Multi Display FOX-MD1 can at any time be connected to the FOX-220 by simple plug-in. This allows the current voltages and flows to be displayed, even graphically. The programming function of the FOX-MD1 enables you to change and save various parameters.
Status Informations
The LEDs at the front of the controller give information on the charging state of the battery, status of the consumer connection and whether a charge current is flowing from the modules or whether the battery is fully charged.
Discharge Protection
The adaptive total discharge protection monitors and protects the battery against damaging total discharge, and alternatively the nightlight function can be used. When using the nightlight function, a consumer will be switched on during the time the modules do not supply charge current (i.e. when it is dark). Ideal for the operation of an orientation light or small lights for the prevention of break-ins.
